User’s Manual
202
Table 5-49 Abandoned object parameters
Name Enter the customized rule name.
Duration
Configure the minimum time period for activating alarms by detecting
the abandoned objects.
Filtering Target
Click to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum size).
When the target that is crossing the tripwire is smaller than the minimum
size or larger than the maximum size, no alarms will be activated. The
maximum size should be larger than the minimum size.
Preset In the
list, select the preset that you want to configure the rule for.
4) Drag to draw an area.
5) Click
OK to save the settings.
Click to set the actions to be triggered. For details, see "5.11.3.1.2 Configuring Tripwire
Rules."
Select the Enable check box, and then click Apply.
The abandoned object detecting function is active.
5.11.3.1.5 Configuring Missing Rules
When the target is taken away from the defined detection area exceeds the set time, the system
activates alarms.
On the rule line that you added, in the Type list, select Missing Object.
Missing object
