Dahua Technology DH-XVR1B16H User Manual

User’s Manual
286
Table 5-75 Firewall parameters
Parameter
Description
Mode
Mode can be configured when Type is Network Access.
●
If
Allowlist
is enabled, you can visit device port successfully with
IP/MAC hosts in the allowlist.
● If
Blocklist
is enabled, you cannot visit device port with IP/MAC hosts
in blocklist.
Add
When Type is Network Access, you can configure IP Address, IP Segment
and MAC Address.
Type You can select IP address, IP segment and MAC address.
IP Address Enter IP Address, Start Port and End Port that is allowed or forbidden.
When Type is IP Address, they can be configured. Start Port and End Port
can be configured only in Network Access Type.
Start Port
End Port
Start Address/End
Address
Enter Start Address and End Address of IP Segment.
When Type is IP Segment, they can be configured.
MAC Address
Enter MAC Address that is allowed or forbidden
When Type is MAC Address, it can be configured.
Step 4 Click Apply to complete the settings.
5.19.3.2 Account Lockout
Step 1 Select Main Menu > SECURITY > Attack Defense > Account Lockout.
Step 2 Set parameters.
Table 5-76 Lockout parameters
Parameter
Description
Attempt(s)
Set the maximum number of allowable wrong password entries.
The account will be locked after your entries exceed the
maximum number.
Value range: 5–30.
Default value: 5.
Lock Time
Set how long the account is locked for.
Value range: 5–120 minutes.
Default value: 5 minutes.
Step 3 Click Apply to complete the settings.

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
