Dahua Technology DH-XVR1B16H User Manual

User’s Manual
334
Manufacturer
Series
Model
Capacity
Port Mode
WD WD Purple WD40PURX 4 TB SATA
WD WD Purple WD50PURX 5 TB SATA
WD WD Purple WD60PURX 6 TB SATA
WD WD Purple WD80PUZX 8 TB SATA
WD WD Purple WD10PURZ 1 TB SATA
WD WD Purple WD20PURZ 2 TB SATA
WD WD Purple WD30PURZ 3 TB SATA
WD WD Purple WD40PURZ 4 TB SATA
WD WD Purple WD50PURZ 5 TB SATA
WD WD Purple WD60PURZ 6 TB SATA
WD WD Purple WD80PURZ 8 TB SATA
WD WD Purple WD4NPURX 4 TB SATA
WD WD Purple WD6NPURX 6 TB SATA
TOSHIBA Mars DT01ABA100V 1 TB SATA
TOSHIBA Mars DT01ABA200V 2 TB SATA
TOSHIBA Mars DT01ABA300V 3 TB SATA
TOSHIBA Sonance MD03ACA200V 2 TB SATA
TOSHIBA Sonance MD03ACA300V 3 TB SATA
TOSHIBA Sonance MD03ACA400V 4 TB SATA
TOSHIBA Sonance MD04ABA400V 4 TB SATA
TOSHIBA Sonance MD04ABA500V 5 TB SATA
Seagate Constellation ES series
(SATA interface)
ST1000NM0033 1 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST2000NM0033 2 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST3000NM0033 3 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST4000NM0033 4 TB SATA
Seagate Constellation ES series
(SATA interface)
ST1000NM0055 1 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST2000NM0055 2 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST3000NM0005 3 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST4000NM0035 4 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST6000NM0115 6 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST8000NM0055 8 TB SATA
Seagate
Constellation ES series
(SATA interface)
ST10000NM0016 10 TB SATA

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
