158
Figure 2-33
The HCVR5108HE-V2 series rear panel is shown as below. See Figure 2-67.
Figure 2-34
The HCVR5116HE-V2 series rear panel is shown as below. See Figure 2-35.
Figure 2-35
Please refer to the following sheet for detailed information.
SN
Icon
Name
Note
1
Power on-off
button
Power on/off button.
