Dahua HCVR5104C Series User Manual

247
Figure 4-36
Please refer to the following sheet for more information.
SN
Name
Function
1
Display
window
 Here is to display the searched picture or file.
 Support 1/4/9/16-window playback.
2
Search
type
 Here you can select to search the picture or the recorded file.
 You can select to play from the read-write HDD, from peripheral device or from
redundancy HDD.
 Before you select to play from the peripheral device, please connect the
corresponding peripheral device. You can view all record files of the root directory
of the peripheral device. Click the Browse button; you can select the file you want to
play.
 Check the box here; you can enable splice playback function. Please refer to
chapter 4.9.1.4 for detailed information.
Important
 Redundancy HDD does not support picture backup function, but it
supports picture playback function. You can select to play from redundancy
HDD if there are pictures on the redundancy HDD.
3
Calendar
 The blue highlighted date means there is picture or file. Otherwise, there is no
picture or file.
 In any play mode, click the date you want to see, you can see the
