2.3 VTO1210C-X
2.3.1 Screw
Component
Illustration
Quantity
M4×40 inner hex flower countersunk flat
head screws-stainless steel
4
2.3.2 Installation Steps
Step 1. Embed plastic housing into wall.
Step 2. Fix device on the bracket with screw.
Figure 2- 3
2.3.3 Wiring
Please refer to Ch 1.2.3.2.
