3 About the system
Depending on the system layout, the system can:
▪ Heat up a space
▪ Cool down a space
▪ Produce domestic hot water
INFORMATION
Cooling is only applicable in case a conversion kit (EKHVCONV*) is installed.
INFORMATION
If underfloor heating is installed in the main zone, then in cooling mode the main
zone can only provide refreshment. Real cooling is then NOT allowed.
3.1 Components in a typical system layout
g
A
db
a
f
e
c
BC
A Main zone. Example: Living room.
B Additional zone. Example: Bedroom.
C Technical room. Example: Garage.
a Outdoor unit heatpump
b Indoor unit heatpump
c Domestic hot water (DHW) tank
d User interface of the indoor unit
e Dedicated Human Comfort Interface (BRC1HHDA used as room thermostat)
f Underfloor heating
g Radiators, heatpump convectors, or fancoil units
