ConTroller operaTIon
Circuit Test Mode Set Points
Circuit test mode set points can be changed when either the unit mode is Test, or the circuit mode is Test. When neither the unit nor
the circuit are in Test mode, all the circuit test mode set points for the circuit are automatically changed back to their ‘off’ values.
Description Default Range
Test 100% VR Solenoid Output Off Off, On
Test 75% VR Solenoid Output Off Off, On
Test 50% VR Solenoid Output Off Off, On
Test Liquid Line Solenoid Output Off Off, On
Test Liquid Injection Solenoid Output Off Off, On
Test Evaporator EXV Position 0% 0 to 100%
Test Economizer EXV Position 0% 0 to 100%
Test Condenser Fan Output 1 Off Off, On
Test Condenser Fan Output 2 Off Off, On
Test Condenser Fan Output 3 Off Off, On
Test Condenser Fan Output 4 Off Off, On
Test Condenser Fan Output 5 Off Off, On
Test Condenser Fan Output 6 Off Off, On
Test Condenser Fan VFD Speed 0% 0 to 100%
NOTE: Settings for outputs should be available based on the selected unit conguration settings.
