InTroduCTIon
General Description
Daikin Pathnder
®
model AWV chillers are complete, self-
contained, automatically controlled, liquid-chilling units
featuring variable speed screw compressors. All model
AWV chillers are equipped with a single evaporator and
microchannel condenser coils along with two compressors.
Pathnder
®
chillers are designed for outdoor installation only.
The chillers use refrigerant HFC-134a that has no ozone
depletion level.
Only normal eld connections such as water piping, electric
power, and control interlocks are required, thereby simplifying
installation and increasing reliability. Necessary equipment
protection and operating controls are included.
All Daikin Applied screw chillers must be commissioned by
a Daikin Applied service technician or an authorized service
provider. Failure to follow this startup procedure can affect the
equipment warranty (see “Receiving and Handling” on page
7).
The standard limited warranty on this equipment covers parts
that prove defective in material or workmanship. Specic
details of this warranty can be found in the warranty statement
furnished with the equipment.
NOMENCLATURE
A W V ### A XXX
Table 1: Operating Limits for AWV Chillers
Maximum standby ambient temperature
NOTE: Maximum operating ambient temperature is determined by unit conguration.
130°F (54.4°C)
Minimum operating ambient temperature - standard ambient control 32°F (0°C)
Minimum starting ambient temperature - low ambient control option -10°F (-23.3°C)
Minimum operating ambient temperature - low ambient control option -20°F (-28.9°C)
Leaving chilled water temperature 40°F to 70°F (4.4°C to 21.1°C)
Leaving chilled uid temperatures (with antifreeze) -
NOTE: Unloading is not permitted with uid leaving temperatures below 25°F (-3.9°C).
17°F to 70°F (-8.3°C to 21.1°C)
Operating chilled water Delta T range 6°F to 20°F (3.3°C to 11.1°C)
Maximum evaporator operating inlet uid temperature 88°F (31.1°C)
Maximum evaporator non-operating inlet uid temperature 100°F (38°C)
Air-cooled
World
Variable Speed Chiller
Compressor Code
Vintage
Number of Fans
