Daikin AWV024 - Recommended Horizontal or Downflow Suction Line Size; Recommended Liquid Line Size

InsTallaTIon and applICaTIon ConsIderaTIons - remoTe evaporaTors
www.DaikinApplied.com 29 IOM 1242-2 • PATHFINDER
®
MODEL AWV CHILLERS
Table 6: Sizing Guidelines for Horizontal or Downow Suction Lines and Liquid Lines
NOTE: Target suction temperature loss less than 2.5°F.
Minimum suction line gas velocity target 1000 FPM
on horizontal and downow piping installations where
the evaporator is at or below the chiller elevation.
Maximum allowable suction line temperature loss
target 5°F; some selections are greater than 5°F
due to minimum velocity requirements at minimum
compressor speed.
Recommended Horizontal or Downow Sucon Line Size
Nominal
Circuit
Capacity
Esmated Line
TEL () Line Material
Sucon Line
Size (Inches)
65 150 Copper 3 5/8
90 150 Copper 4 1/8
115 150 Copper 4 1/8
140 150 Copper 5 1/8
165 150 Copper 5 1/8
190 150 Copper 6 1/8
215 150 Copper 6 1/8
240 150 Copper 6 1/8
265 150 Copper 6 1/8
65 175 Copper 4 1/8
90 175 Copper 4 1/8
115 175 Copper 4 1/8
140 175 Copper 5 1/8
165 175 Copper 5 1/8
190 175 Copper 6 1/8
215 175 Copper 6 1/8
240 175 Copper 6 1/8
265 175 Copper 6 1/8
65 200 Copper 4 1/8
90 200 Copper 4 1/8
115 200 Copper 4 1/8
140 200 Copper 5 1/8
165 200 Copper 5 1/8
190 200 Copper 6 1/8
215 200 Copper 6 1/8
240 200 Copper 6 1/8
265 200 Copper 6 1/8
65 225 Copper 4 1/8
90 225 Copper 4 1/8
115 225 Copper 4 1/8
140 225 Copper 5 1/8
165 225 Copper 5 1/8
190 225 Copper 6 1/8
215 225 Copper 6 1/8
240 225 Copper 6 1/8
265 225 Copper 6 1/8
Recommended Liquid Line Size
Nominal
Circuit
Capacity
Esmated Line
TEL () Line Material
Liquid Line Size
(Inches)
65 150 Copper 1 5/8
90 150 Copper 2 1/8
115 150 Copper 2 1/8
140 150 Copper 2 1/8
165 150 Copper 2 1/8
190 150 Copper 2 5/8
215 150 Copper 2 5/8
240 150 Copper 2 5/8
265 150 Copper 2 5/8
65 175 Copper 1 5/8
90 175 Copper 2 1/8
115 175 Copper 2 1/8
140 175 Copper 2 1/8
165 175 Copper 2 5/8
190 175 Copper 2 5/8
215 175 Copper 2 5/8
240 175 Copper 2 5/8
265 175 Copper 2 5/8
65 200 Copper 1 5/8
90 200 Copper 2 1/8
115 200 Copper 2 1/8
140 200 Copper 2 1/8
165 200 Copper 2 5/8
190 200 Copper 2 5/8
215 200 Copper 2 5/8
240 200 Copper 2 5/8
265 200 Copper 3 1/8
65 225 Copper 2 1/8
90 225 Copper 2 1/8
115 225 Copper 2 1/8
140 225 Copper 2 5/8
165 225 Copper 2 5/8
190 225 Copper 2 5/8
215 225 Copper 2 5/8
240 225 Copper 3 1/8
265 225 Copper 3 1/8
