ESIE15-13B Troubleshooting by Remote Controller
Service Diagnosis 153
4.21 Low Pressure Switch System Abnormality
Remote
Controller
Display
H4
Applicable
Models
RZQG71~140
Method of Error
Detection
Check the continuity of LPS.
Error Decision
Conditions
When there is no continuity in the LPS during compressor start operating.
Supposed
Causes
Faulty LPS
Disconnection in LPS harness
Faulty connection of LPS connector
Defect of outdoor unit PC board
Refrigerant shortage
Stop valve is not opened
Defective expansion valve
Troubleshooting
Note:
*1 Verify why pressure in the unit is abnormally low
*2 LPS resistance (closed contact) should be < 10Ω
Connect correctly.
Replace the outdoor control
PC board.
NO
Caution
Be sure to turn off power switch before connect or disconnect connector, or parts damage may be occurred.
Turn off the power supply.
After 10 minutes, check the following.
YES
Correct the refrigerant pipe.
NO
YES
Replace the LPS.
NO
YES
Is LPS connector connected
to outdoor PC board?
Is low pressure
abnormally low? (*1)
Is there continuity in control and
protection LPS? (*2)
CHECK 7
To Next Page
