Field Setting from Remote Controller ESIE15-13B
70 Field Setting
Airflow Rate
Set the airflow when thermostat OFF by the combination of "Fan OFF at Thermostat OFF"
11(21)-2, "Fan speed heating thermostat OFF" 12(22)-3 and "Fan speed cooling thermostat
OFF" 12(22)-6.
A : 6 minutes OFF / 1 minute LL
B : 6 minutes OFF / 1 minute setting airflow
C : 6 minutes OFF / 1 minute L
Set the airflow by the combination of 3 modes as below.
Airflow Rate Setting during Heating (FCQG Only)
For the purpose of securing airflow range during heating, the number of revolutions of fan during
heating can be changed. Make the setting according to installation environment.
Mode No. First Code No.
Second Code No.
Factory
setting
Field setting
11(21) 2 0101010102020202
12(22) 3 0101020201010202
12(22) 6 0201010201020102
Cooling
When thermostat
OFF
SettingLLLLSettingABAB
Dry
When thermostat
OFF
CCCCCCCC
Heating
When thermostat
OFF
LL LL Setting Setting A A Setting Setting
When defrost hot
start
OFF OFF OFF OFF OFF OFF OFF OFF
Mode No. First Code No.
Second Code No.
01 02 03
11 (21) 3 Standard Slightly up Up
To Next Page
