ESIE15-13B
Field Setting from
Remote Contro
ller
Field Setting
79
Graph 2
Target evaporating temperature control when "low humidity application" is selected. Field
setting 16(26)-2-03:
Te target
(˚C)
Te target acceptable area
Remote con
troller settin
g temp.
Te target limited
≤
20˚C
(to protect the
comp.)
Te (s
ee note) ta
rget acceptable area
Indoor temp.
>
setting
→
Te target down
Indoor temp.
<
setting
→
Te
target up
Te target limited
≥
0˚C
Freeze p
rotec
tion
(40 min. integrated coil te
mp.
≤
-1˚C)
Indoor Temp
(˚C DB)
92
94
