Si04-756 Removal of Front Grille
Removal Procedure 13
3
The front panel
mechanism assembly
is fixed to the front
grille.
Check that the arm is in
the stored position.
4
Installation structure
5
Movement of the arm
Step Procedure Points
(R13954)
Front panel mechanism assembly
Arm
(R5662)
(R5663)
