Removal of Dehumidifying Solenoid Valve Coils Si04-756
30 Removal Procedure
8. Removal of Dehumidifying Solenoid Valve Coils
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Step Procedure Points
Preparation
Remove the front grille
according to "Removal of
Front Grille".
1
Disconnect the
connector for the
dehumidifying solenoid
valve coils [S43].
2
Pull out the
dehumidifying solenoid
valve coils to remove.
The dehumidifying solenoid
valve coils do not need
screws.
Dehumidifying solenoid valve coil
(R5717)
(R14155)
Dehumidifying solenoid valve coil
[S43]
(R5719)
To Next Page
