Si04-756 Removal of PCBs
Removal Procedure 29
6
Unfasten the 3 hooks
and remove the display
PCB and the signal
receiver / transmitter
PCB.

The display PCB and the
signal receiver / transmitter
PCB are united.
Step Procedure Points
(R5715)
Hooks
(R13967)
Display PCB
Signal receiver / transmitter PCB
