Si04-756
Removal Procedure 1
Table of Contents
1. Removal of Air Filters / Front panel.........................................................2
2. Removal of Upper Panel .........................................................................8
3. Removal of Front Grille .........................................................................11
4. Removal of Front Panel Mechanism Assembly ....................................14
5. Removal of Reduction Motor Assembly ................................................16
6. Removal of Electrical Box .....................................................................19
7. Removal of PCBs..................................................................................24
8. Removal of Dehumidifying Solenoid Valve Coils ..................................30
9. Removal of Connecting Duct ................................................................31
10.Removal of Drain Hose .........................................................................33
11.Removal of Swing Motors .....................................................................35
12.Removal of Indoor Heat Exchanger ......................................................37
13.Removal of Fan Rotor / Fan Motor........................................................40
14.Removal of Horizontal Blades / Vertical Blades....................................43
15.Removal of Streamer Unit.....................................................................45
Note:
î
The illustrations may be slightly different depending on the model.
