Table 2. Pirahna2 Performance Specifications, 1kHz line rate, 40MHz Model
Min. Gain Nom. Gain Max. Gain
Environment Conditions
Units Min Typ Max Min Typ Max Min Typ Max Notes
Data Rate (40MHz model) MHz 40 40 40 40 40 40 40 40 40
Line Rate kHz 1 1 1 1 1 1
Gain Setting dB -10 -10 -10 0 0 0 +10 +10 +1
0
Front Plate Temperature °C 30 50 30 50 30 50 3
Electro-Optic Specifications
Units Min Typ Max Min Typ Max Min Typ Max Notes
Broadband Responsivity, 7um pixels DN/(nJ/cm
2
) 3 3.4 3.8 9.4 10.7 12 30 34 38
Broadband Responsivity, 10um pixels DN/(nJ/cm
2
) 6 6.8 7.6 18.8 21.4 24 60 68 76
Dynamic Range Ratio 496:1 207:1 390:1 62:1 135:1
Pk-Pk Noise, max DN 2 3 4 8 15 32 4
RMS Noise, max DN 0.5 0.5 0.75 1.2 2.2 4 4
FPN uncorrected, max 4K and under DN 1.1 4 3.5 8 8 27 5
FPN uncorrected, max 6K and over DN 1.6 4 4 8 14 27 5
FPN corrected, max DN 0.3 2 1 2 2 8 2
PRNU uncorrected
1K and 2K, ECD/ECE DN 5 18 5 23 8/10 39
4k, ECD/ECE DN 9 28 10 28 12/2
0
43
6K and 8K, ECD/ECE DN 15 38 16 38 14/2
7
55
PRNU corrected ECD/ECE DN 1.5
/ 2
3 / 3 1.2/
1.5
3/
8
2/3.
5
5/
27
2
DC Offset DN
4k and under 2 3 5 5 7 17 6
6k and over 2 3 5 5 14 17 6
Notes:
DN = Digital Numbers (0-255); also known as gray levels.
ECE = Exposure Control Enabled
ECD = Exposure Control Disabled
• All measurements taken in 8-bit output mode.
• All measurements are valid for front plate temperatures in still air.
• All measurements used a Tungsten halogen light source, 3200K bulb temp., and
750nm cutoff filter
1. All specifications for the 30MHz model are preliminary.
2 Due to FPN/PRNU correction calculations, certain digital numbers will be
unavailable when outputting 10 bits with FPN/PRNU correction.
3 Measured at front plate. The corresponding ambient temperature range with still air
is 0°C - 37°C.
4 Measurements taken at maximum line rates.
