9 Piranha2 User’s Manual
Table 1. Piranha2 Operating Requirements and Ranges
Operating Requirements Units Typical Notes
Power
1024—2 o/p W 6
2048—2 /4 o/p W 6 / 8.5
4096 (7µm)—2 / 4 o/p W 6 / 8.5
4096 (10µm)—2 o/p W 9
4096 (10µm)—4 o/p W 11
6144—2 / 4 o/p W 7 / 9.5
8192 —2 / 4 o/p W 7.5 / 10
Power Supply Current (Vin = +12V)
1024—2 o/p mA 480
2048—2 /4 o/p mA 500 / 700
4096—2 / 4 o/p mA 500 / 690
4096 (10µm)—2 o/p mA 750
4096 (10µm)—4 o/p mA 900
6144—2 / 4 o/p mA 650 / 850
8192 —2 / 4 o/p mA 680 / 900
Time to power up, typ sec. 15
Time to calibrate (FPN/PRNU)
1024 sec. 10
2048 sec. 19
4096 sec. 38
6144 sec. 85
8192 sec. 115
Specification Units Min Max
40 MHz
Notes
Data Rate, per tap (40 MHz model) MHz 40 40
(30 MHz model) MHz 30 30 1
Specification Units Min Max
30 MHz
Max
40
MHz
Line Rate
1024, 2 o/p kHz 1 49.6 65.3 1
2048, 2 o/p kHz 1 27 35.4 1
2048, 4 o/p kHz 1 68 1
4096, 2 o/p kHz 1 14 18.5 1
4096, 4 o/p kHz 1 36.2
6144, 2 o/p kHz 1 12.3
6144, 4 o/p kHz 1 24.4
8192, 2 o/p kHz 1 7.15 9.3
8192, 4 o/p kHz 1 18.6
Temperature
Front plate Temperature °C 10 50 2
