SPEED SENSOR INSTALLATION
23Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
Position of clamp must be 180° in relation to position sign on speed sensor clamp must be fixed
Item Description Qty
1 Support speed sensor 1
2 Screw 1
3 O-ring DIA 15x1.8 1
4 Assy speed sensor AMP 1
Transmission model. ASSY Part Nr Connector Type X Position
6000 4209752 AMP 2 pins Drum speed 180°
