DANA SPICER 6000 EHO - Forward 4 th Speed Hydraulic Circuit

40
POWER FLOWS, SOLENOIDS AND HYDRAULIC CIRCUITS
Dana Incorporated TSM-0238 - 6000 Transmission Service Manual
FORWARD 4TH SPEED
36
31
34
37
41
42
43
44
46
45
1ST
CLUTCH
2ND
CLUTCH
3RD
CLUTCH
4TH
CLUTCH
REV
CLUTCH
FWD
CLUTCH
Lubrication
Low pressure 0 - 6 bar High pressure 0 - 20 bar
Drain
SCREEN
FILTER
AIR
BREATHER
PUMP
OIL SUMP
PRESSURE
REGULATOR
VALVE
12.4-15.2 bar
PRESSURE
REDUCER
8.5-11 bar
Ø 0.8
SAFETY VALVE
7.6-9.0 bar
CONVERTER REGULATOR
3.8 - 4.0 bar
TORQUE
CONVERTER
LUBRICATION
HOSE
HOSE
HOSE
HOSE
HOSE
HOSE
COOLER
1ST
1ST 2ND
3RD
4TH
2ND
3RD
4TH
FWD
REV
FWD
REV
