DANA SPICER 6000 EHO - Disassembly and Assembly; Disassembly Procedures Overview

97Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
DISASSEMBLY & ASSEMBLY
DISASSEMBLY
FIGURE 1: Cover photo.
FIGURE 2: Remove 13x cap-screws + washers (size 5/8).
FIGURE 3: Remove valve using 2x eyebolt (M14) and 2x gui-
de pins.
FIGURE 4: Remove gasket.
FIGURE 5: Remove 6x O-rings.
