ASSY-SOLENOID PLATE
85Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
ASSY-SOLENOID PLATE
ITEM DESCRIPTION QTY
1 PLATE-SOLENOID NON TOTAL NEUTRAL 1
2SCREW 3
3 CLAMP-SOLENOID 1
4 SOLENOID 24V 6
5RING-SNAP 6
6SCREW M5 6
7DISC-FILTER 6
8 PLUG-RESTRICTION DIA. 0,8 1
9 STRAP 2,4 X 200 MM 4
10 SCREW M5 1
11 CLAMP WIRING 1
12 LOCKWASHER 1
