DANA SPICER 6000 EHO - Page 84

84
ASSY-CONTROL VALVE - 2
Dana Incorporated TSM-0238 - 6000 Transmission Service Manual
APPLY LOCTITE NO. 5205
BETWEEN ADAPTER AND VALVE
10
APPLY LOCTITE NO. 243 OR 245
SOLENOID 3RD CLUTCH
WIRE COLOR WHITE
SOLENOID FWD CLUTCH
WIRE COLOR BLACK
SOLENOID 1ST CLUTCH
WIRE COLOR YELLOW
SOLENOID 2ND CLUTCH
WIRE COLOR GREEN
SOLENOID REV CLUTCH
WIRE COLOR BLUE
SOLENOID 4TH CLUTCH
WIRE COLOR ORANGE
