CHECK POINT
Dana Incorporated TSM-0238 - 6000 Transmission Service Manual
NUMBERING OF PORTS FOR HYDRAULIC CIRCUIT DIAGRAMS
PORTS PRESSURE CHECK PORTS TEMPERATURE CHECK PORTS
1 31 Regulated Clutch pressuure 71 To Cooler
2 32 To Cooler 72
3 33 From Cooler 73
4 34 Lube 74
5 35 Pump 75
6 36 Solenoid 76
7 37 Converter In 77
83878
93979
10 40 80
11 To Cooler 41 1st Clutch 81
12 From Cooler 42 2nd Clutch 82
13 To Remote Filter (on Transmission) 43 3rd Clutch 83
14 From Transmission (on Remote Filter) 44 FWD High 84
15 To Transmission (on Remote Filter) 45 FWD Low 85
16 From remote Filter (on Transmission) 46 REV Clutch 86
17 Air/Hydr Disconnect - 4WD 47 Disconnect Clutch 87
18 To Pump 48 Clutch Return Line 88
19 Air/Hydr Inching 49 SAHR Brake Release 89
20 Air/Hydr Disconnect - 2WD 50 VFS 1st 90
21 From Pump 51 VFS 2nd
22 Drain 52 VFS 3rd
23 From Regulator 53 VFS High
24 SAHR brake Release 54 VFS FWD
25 Range - Shift 55 VFS REV
26 Diff. Lock 56 System Pressure (after Total Neutral)
27 Power Brake Supply 57 Pilot Pressure
28 Clutch Return Line 58 Pressure Check Range Clutches
29 From Pump for Brake Release 59 Pressure Check Direct. Clutches
30 60 Pressure Intensifier 1st
61 Pressure Intensifier 2nd
62 Pressure Intensifier 3rd
63 Pressure Intensifier High
64 Pressure Intensifier FWD
65 Pressure Intensifier REV
66
NOTE:
For ports drawings see chapter Installation detail p. 18
