ASSY-CONTROL VALVE WITH VARIABLE RESTRICTIONS
87Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
ITEM DESCRIPTION QTY
1 SPOOL-BODY NON TOTAL NEUTRAL 1
2 COVER PRESSURE REGULATOR 1
3SPRING-INNER 1
4SPRING-OUTER 1
5SPOOL REGULATOR 1
6 GASKET COVER RANGE SPOOLS 1
7 COVER-RANGE SPOOLS 1
8SPOOL-OFF/ON 4
9SPRING 4
10 SPRING-SPOOL SLECTOR 2
11 PLATE-SEPARATER 1
12 SPRING PRESSURE REDUCER 1
13 SPOOL-PRESSURE REDUCER 1
14 SPOOL-STOP 4
15 PARALLEL PIN 4
16 SPOOL-FWD/N/REV 1
17 SPOOL-ACCUMULATOR 6
18 COVER-SAFETY VALVE 1
19 PLUG-RESTRICTION 5/16-24UNF DIA .032 FWD-
REV
2
20 PLUG-RESTRICTION 5/16-24UNF DIA .045 3RD-
4TH
2
21 PLUG-RESTRICTION 5/16-24UNF DIA .042 1ST-
2ND
2
22 GASKET COVER DIRECTION SPOOLS 1
23 COVER-DIRECTION SPOOLS 1
24 SEAT-SAFETY VALVE 1
25 SAFETY VALVE SPACER 1
26 BALL 1
27 SPRING-SAFETY VALVE 1
28 SCREW 28
29 PLUG-SCREW TYPE 10
30 O-RING 10
31 SPRING MIDDLE SOFT ACCUMULATOR 6
32 SPRING-HELICAL 6
33 PIN-STOP HARD ACCUMULATOR 6
34 ASSY-MODULATOR SPOOL 2
35 ASSY-MODULATOR SPOOL 2
36 ASSY-MODULATOR SPOOL 1
37 ASSY-MODULATOR SPOOL 1
38 PLUG 6
39 O-RING 2
ITEM DESCRIPTION QTY
