GROUP-OUTPUT SHAFT
93Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
ITEM DESCRIPTION QTY
1SHAFT-OUTPUT 1
2 GEAR-2ND AND 4TH 41T 1
3 GEAR-1ST AND 3RD 54T 1
4CUP-BEARING 2
5CONE-BEARING 2
6 ASSY-BRG.CAP AND OIL SEAL 2
7 SEAL-OIL - PART OF ITEM 6 1
8 O-RING-BEARING CAP 2
9 SHIM-BEARING CAP .004 A/R
10 SHIM-BEARING CAP .007 A/R
11 SHIM-BEARING CAP .010 A/R
12 SCREW-BEARING CAP 12
13 Not Used On This Model
14 O-RING FLANGE 2
15 WASHER-FLANGE 2
16 NUT-FLANGE 2
