D&R Electronica Weesp BV (CINEMIX PARTLIST) DATE: 24-04-1998
Page 2
60883307 Cinemix film master 60883308 Cinemix master
------------------------------------------------------------------------------------------------- -------------------------------------------------------------------------------------------------
Articlecode | Description | Quantity | Unit Articlecode | Description | Quantity | Unit
------------------------------------------------------------------------------------------------- -------------------------------------------------------------------------------------------------
10350859 | Weerstand 24k3 1% 1/4W | 4.0000 | st 10950470 | Batterij 3V (lithium knoopcel) | 1.0000 | st
10350746 | Weerstand 27k 5% 1/4W | 3.0000 | st 10950471 | Batterij houder knoopcel | 1.0000 | st
10350713 | Weerstand 47E 5% 1/4W | 64.0000 | st 10400213 | Condensator ker 10p R2.5 | 106.0000 | st
10350749 | Weerstand 47k 5% 1/4W | 28.0000 | st 10400216 | Condensator ker 18p R2.5 | 10.0000 | st
10350714 | Weerstand 56E 5% 1/4W | 1.0000 | st 10400217 | Condensator ker 22p R2.5 | 13.0000 | st
10350717 | Weerstand 100E 5% 1/4W | 8.0000 | st 10400221 | Condensator ker 47p R2.5 | 8.0000 | st
10350753 | Weerstand 100K 5% 1/4W | 99.0000 | st 10400223 | Condensator ker 68p R2.5 | 28.0000 | st
10350719 | Weerstand 150E 5% 1/4W | 4.0000 | st 10401241 | Condensator ker 100nF/50V R5 T | 252.0000 | st
10350755 | Weerstand 150K 5% 1/4W | 2.0000 | st 10401246 | Condensator poly 1n0 R5.0 | 3.0000 | st
10350720 | Weerstand 180E 5% 1/4W | 1.0000 | st 10401268 | Condensator poly 1uF R5.0 | 2.0000 | st
10350756 | Weerstand 180K 5% 1/4W | 3.0000 | st 10401250 | Condensator poly 4n7 R5.0 | 2.0000 | st
10350721 | Weerstand 220E 5% 1/4W | 5.0000 | st 10401253 | Condensator poly 10n R5.0 | 12.0000 | st
10350757 | Weerstand 220K 5% 1/4W | 3.0000 | st 10401258 | Condensator poly 47n R5.0 | 1.0000 | st
10350891 | Weerstand 324E 1% 1/4W | 2.0000 | st 10401242 | Condensator poly 82n R5.0 | 12.0000 | st
10350725 | Weerstand 470E 5% 1/4W | 10.0000 | st 10401261 | Condensator poly 100n R5.0 | 3.0000 | st
10350761 | Weerstand 470k 5% 1/4W | 21.0000 | st 10400269 | Condensator poly 220n R5.0 | 1.0000 | st
10350726 | Weerstand 560E 5% 1/4W | 22.0000 | st 10400270 | Condensator poly 470n R5.0 | 3.0000 | st
10350864 | Weerstand 649E 1% 1/4W | 2.0000 | st 10250342 | Diode 1N4148(signaal) | 28.0000 | st
10350029 | Weerstand 680E array sil8 ncom | 26.0000 | st 10400279 | Elco 1uF / 63V radiaal R5.0 | 5.0000 | st
10350763 | Weerstand 680k 5% 1/4W | 12.0000 | st 10400284 | Elco 10uF / 40V radiaal R5.0 | 2.0000 | st
10350031 | Weerstand array 8x 10k 9p SIL | 1.0000 | st 10400286 | Elco 22uF / 50V radiaal R5.0 | 3.0000 | st
10250340 | Zenerdiode 2V4 / 400mW | 7.0000 | st 10400287 | Elco 47uF / 25V radiaal R5.0 | 1.0000 | st
10250351 | Zenerdiode 5V6 / 400mW | 4.0000 | st 10400292 | Elco 100uF / 25V radiaal R5.0 | 162.0000 | st
10250353 | Zenerdiode 12V0 / 1W | 5.0000 | st 10400280 | Elco 2.2uF / 50V radiaal R5.0 | 1.0000 | st
10250359 | Zenerdiode 15V0 / 400mW | 1.0000 | st 10400290 | Elco 220uF / 25V radiaal R5.0 | 37.0000 | st
10250350 | Zenerdiode 18V0 / 400mW | 3.0000 | st 10250270 | Fet BST76a /BS107 (Nch switch) | 1.0000 | st
10700652 | Afstandshdr pl zeskant+tap15mm | 1.0000 | st 10250338 | Fet J112 (N-channel switch) | 3.0000 | st
10650446 | Bandkabel 10p (R 1.27) | 10.0000 | cm 10250017 | Fet J175 (P-channel switch) | 3.0000 | st
10650448 | Bandkabel 20p (R 1.27) | 60.0000 | cm 10600452 | Header 10p haaks (raster 2.54) | 2.0000 | st
10650159 | Bandkabel 34p (R 1.27) | 160.0000 | cm 10600540 | Header 10p recht (raster 2.54) | 1.0000 | st
10600173 | Conn: 3p wrd:402-03*20cm 2.5T | 2.0000 | st 10600509 | Header 20P Straight | 3.0000 | st
10600169 | Conn: 4p wired:1=blk/grn/rd/bl | 2.0000 | st 10600510 | Header 2p Lock straightR 2.54) | 1.0000 | st
10600434 | Connector bandkabel female 10p | 2.0000 | st 10600511 | Header 3p Lock straightR 2.54) | 4.0000 | st
10600466 | Connector bandkabel female 16p | 6.0000 | st 10600512 | Header 4P lock straight(R2.54) | 18.0000 | st
10600132 | Connector bandkabel female 34p | 8.0000 | st 10600515 | Header haaks 4p lock (R 2.54) | 1.0000 | st
10600136 | Connector bandkabel male 20p | 8.0000 | st 10600521 | Header haaks 16p box (R 2.54) | 2.0000 | st
10450153 | Deksel SiFam 11mm black/5bulk | 5.0000 | st 10600456 | Header haaks 20p (raster 2.54) | 5.0000 | st
10450195 | Deksel SiFam 11mm gray bulk | 10.0000 | st 10600140 | Header haaks 34p (raster 2.54) | 6.0000 | st
10450016 | Deksel Sifam 21mm red bulk | 2.0000 | st 10600141 | Header haaks 64p (raster 2.54) | 8.0000 | st
10550100 | Encoder ECW 1 JB 24 BC 0024 | 1.0000 | st 10600478 | Header recht 4p (raster 2.54) | 9.0000 | st
10300090 | Fader JP 100mm stereo 10KA | 1.0000 | st 10600435 | Header recht 10p nobox(R 2.54) | 4.0000 | st
10101191 | Front Cinemix 11A (master VU) | 1.0000 | st 10600520 | Header recht 16p box (R 2.54) | 4.0000 | st
10101180 | Front Cinemix film naster | 1.0000 | st 10600518 | Header recht 20p box (R 2.54) | 1.0000 | st
10300461 | Joystick RKJXB1210 10KBx2 ALPS | 2.0000 | st 10600142 | Header recht 34p (raster 2.54) | 8.0000 | st
10450209 | Knop Druktoets 2.8 black-squar | 12.0000 | st 10250026 | Ic 27C512-10 EPROM 64K 100ns | 1.0000 | st
10450211 | Knop Druktoets 2.8 grey-rectan | 12.0000 | st 10250040 | Ic 40106B (hex schmitt trig) | 5.0000 | st
10450208 | Knop Druktoets 2.8 grey-square | 14.0000 | st 10250025 | Ic 4051B (8 chann multiplexer) | 3.0000 | st
10450212 | Knop Druktoets 2.8 red -rectan | 17.0000 | st 10250057 | Ic 4052 (dual analog mux) | 7.0000 | st
10450215 | Knop Druktoets grey 12x12 3.3 | 1.0000 | st 10250004 | Ic 4053B (HCF4053 BEY)switch | 5.0000 | st
10450082 | Knop Fader SiFam white (1.2x8) | 1.0000 | st 10250005 | Ic 4093B (snand) | 1.0000 | st
10450020 | Knop Joystick black stuurknupp | 2.0000 | st 10250094 | Ic 4094 (8bit serial shiftreg) | 9.0000 | st
10450014 | Knop SiFam 21mm grey 6mm shaft | 2.0000 | st 10250014 | Ic 4N27(opto-coupler) | 1.0000 | st
10450103 | Knop SiFam grey splined(11mm) | 15.0000 | st 10250039 | Ic 62C256 (8 bit 32k ram) | 1.0000 | st
10250130 | LCD BT22005 V-STF LED4-GBatron | 1.0000 | st 10250012 | Ic 74HC125 (quad bistab. buf) | 1.0000 | st
10250386 | Led 3mm green round | 55.0000 | st 10250034 | Ic 74HC132 (quad 2inp.schmitt) | 1.0000 | st
10250387 | Led 3mm red round | 26.0000 | st 10250048 | Ic 74HC138 3to8 line decoder | 2.0000 | st
10970912 | Microfoon (condens) (talkback) | 1.0000 | st 10250031 | Ic 74HC148 (8/3 encoder ) | 1.0000 | st
10700690 | Platstaf 25 x 10 x 10mm | 6.0000 | st 10250046 | Ic 74HC259 8 bit adr latch | 1.0000 | st
10101196 | Plexiglas DOT MATRIX Cinemix | 2.0000 | st 10250033 | Ic 74HC573 (octal-D latch) | 1.0000 | st
10101197 | Plexiglas LCD scherm | 1.0000 | st 10250291 | Ic 7805 TO220 SGS (volt.reg) | 5.0000 | st
10700611 | Popnagel 3.0 x 6.5 blank | 12.0000 | st 10250036 | Ic 80C552 (8-bit micro-comptr) | 1.0000 | st
20851223 | Print bestukt Cinemix3 (mstr) | 1.0000 | st 10250275 | Ic LM-1972N (M-DAC) | 9.0000 | st
20851224 | Print bestukt Cinemix4 (mstr) | 1.0000 | st 10250316 | Ic LM-339(comparator) | 3.0000 | st
20851190 | Print bestukt Cinemix41(Pinkn) | 1.0000 | st 10250307 | Ic NE-5532 AP TI (dual-opamp) | 31.0000 | st
20851225 | Print bestukt Cinemix5 (mstr) | 2.0000 | st 10250182 | Ic SSM-2142 P (balanced out) | 2.0000 | st
20851178 | Print bestukt Cinemix6b(mstr) | 1.0000 | st 10250032 | Ic THAT 2180-LB VCA | 6.0000 | st
20851179 | Print bestukt Cinemix7b(keyb1) | 1.0000 | st 10250304 | Ic TL-072 CP TI (dual-opamp) | 33.0000 | st
20851195 | Print bestukt Phase-1 | 1.0000 | st 10250305 | Ic TL-074 CN TI (quad-opamp) | 3.0000 | st
10700786 | Taptite M3x5 verzkop/pozidr/zw | 2.0000 | st 10600394 | Ic-voet 8 pins (vork-contact) | 66.0000 | st
10700787 | Taptite M3x6 bolkoppozidr/zwrt | 30.0000 | st 10600402 | Ic-voet 8 pins SIL 2.54mm | 6.0000 | st
10700790 | Taptite M3x6 verzkop/pozidr/zw | 16.0000 | st 10600395 | Ic-voet 14 pins (vork-contact) | 14.0000 | st
10951003 | VU meter AL19-WF / 24v lamp | 3.0000 | st 10600396 | Ic-voet 16 pins (vork-contact) | 28.0000 | st
10951001 | VU meter AL29-WF / 24v lamp | 3.0000 | st 10600398 | Ic-voet 20 pins (vork-contact) | 10.0000 | st
10600401 | Ic-voet 28 pins (vork-contact) | 2.0000 | st
10600403 | Ic-voet 68 pins (PLCC Socket) | 1.0000 | st
10300166 | Instelpot 10-turn 22k (T18) | 8.0000 | st
10300519 | Instelpot 10-turn 100k (T18) | 1.0000 | st
10300200 | Instelpot 25-turn 20k H T93YB | 2.0000 | st
10450209 | Knop Druktoets 2.8 black-squar | 1.0000 | st
10250396 | Kristal 12.0000 MHz | 1.0000 | st
10250387 | Led 3mm red round | 1.0000 | st
10250407 | Led Matrix 30 mm TC12-11EWA | 2.0000 | st
10700690 | Platstaf 25 x 10 x 10mm | 1.0000 | st
10700611 | Popnagel 3.0 x 6.5 blank | 4.0000 | st
10300378 | Potm16 1x 10kA log | 10.0000 | st
10300372 | Potm16 1x 20kBcn lin | 2.0000 | st
