D&R Electronica Weesp BV (CINEMIX PARTLIST) DATE: 24-04-1998
Page 3
60883308 Cinemix master 10550100 | Encoder ECW 1 JB 24 BC 0024 | 2.0000 | st
------------------------------------------------------------------------------------------------- 10300090 | Fader JP 100mm stereo 10KA | 1.0000 | st
Articlecode | Description | Quantity | Unit 10101191 | Front Cinemix 11A (master VU) | 1.0000 | st
------------------------------------------------------------------------------------------------- 10101185 | Front Cinemix 5B (master) | 1.0000 | st
10300370 | Potm16 2x 10kA log | 2.0000 | st 10300461 | Joystick RKJXB1210 10KBx2 ALPS | 2.0000 | st
10300371 | Potm16 2x 10kBcn lin | 1.0000 | st 10450209 | Knop Druktoets 2.8 black-squar | 6.0000 | st
10201183 | Print Cinemix 3B (master) | 1.0000 | st 10450211 | Knop Druktoets 2.8 grey-rectan | 12.0000 | st
10201184 | Print Cinemix 4B (master) | 1.0000 | st 10450208 | Knop Druktoets 2.8 grey-square | 20.0000 | st
10201185 | Print Cinemix 5A (master) | 2.0000 | st 10450212 | Knop Druktoets 2.8 red -rectan | 21.0000 | st
10201186 | Print Cinemix 6A (master CPU) | 1.0000 | st 10450215 | Knop Druktoets grey 12x12 3.3 | 1.0000 | st
10201187 | Print Cinemix 7A (keyboard 1) | 1.0000 | st 10450082 | Knop Fader SiFam white (1.2x8) | 1.0000 | st
10201188 | Print Cinemix 8A (keyboard 2) | 1.0000 | st 10450020 | Knop Joystick black stuurknupp | 2.0000 | st
10201190 | Print Cinemix41P (pinknoise) | 1.0000 | st 10450014 | Knop SiFam 21mm grey 6mm shaft | 1.0000 | st
10201195 | Print Phase-1A (phasemeter) | 1.0000 | st 10450015 | Knop SiFam 38mm grey 1/4 shaft | 1.0000 | st
10550001 | Relais D1C121000 1xchnge minid | 1.0000 | st 10450103 | Knop SiFam grey splined(11mm) | 15.0000 | st
10550418 | Schakelaar ALPS 6xom mini NS | 3.0000 | st 10250130 | LCD BT22005 V-STF LED4-GBatron | 1.0000 | st
10550205 | Schakelaar Alps 2p mini MOMENT | 17.0000 | st 10250386 | Led 3mm green round | 41.0000 | st
10550395 | Schakelaar Alps 2p-ns (moment) | 1.0000 | st 10250387 | Led 3mm red round | 39.0000 | st
10550414 | Schakelaar Alps 2pole mini NS | 24.0000 | st 10970912 | Microfoon (condens) (talkback) | 1.0000 | st
10550415 | Schakelaar Alps 4pole mini NS | 21.0000 | st 10700690 | Platstaf 25 x 10 x 10mm | 8.0000 | st
10550206 | Schakelaar Zippy Led black mom | 20.0000 | st 10101196 | Plexiglas DOT MATRIX Cinemix | 2.0000 | st
10550204 | Schakelaar Zippy Led gray mom | 9.0000 | st 10101197 | Plexiglas LCD scherm | 1.0000 | st
10550200 | Schakelaar Zippy+led (red) mom | 5.0000 | st 10700611 | Popnagel 3.0 x 6.5 blank | 14.0000 | st
10600414 | Shunt 2p (mini-jumper) | 18.0000 | st 20851223 | Print bestukt Cinemix3 (mstr) | 1.0000 | st
10250335 | Transistor 2SB737 (pnp) | 6.0000 | st 20851224 | Print bestukt Cinemix4 (mstr) | 1.0000 | st
10250333 | Transistor BC-327/25 (pnp) | 5.0000 | st 20851190 | Print bestukt Cinemix41(Pinkn) | 1.0000 | st
10250332 | Transistor BC-337/25 tape(npn) | 3.0000 | st 20851225 | Print bestukt Cinemix5 (mstr) | 2.0000 | st
10350517 | Weerstand 0E 5% 1/4W | 16.0000 | st 20851226 | Print bestukt Cinemix6 (mstr) | 1.0000 | st
10350701 | Weerstand 1E0 5% 1/4W | 4.0000 | st 20851227 | Print bestukt Cinemix7 (key1) | 1.0000 | st
10350729 | Weerstand 1k0 5% 1/4W | 10.0000 | st 20851228 | Print bestukt Cinemix8 (key2) | 1.0000 | st
10350829 | Weerstand 1k07 1% 1/4W | 10.0000 | st 20851195 | Print bestukt Phase-1 | 1.0000 | st
10350827 | Weerstand 1k10 1% 1/4W | 2.0000 | st 10550451 | Schak Miyama WHI OFF(ON)LEDred | 1.0000 | st
10350731 | Weerstand 1k5 5% 1/4W | 1.0000 | st 10700786 | Taptite M3x5 verzkop/pozidr/zw | 2.0000 | st
10350833 | Weerstand 1k50 1% 1/4W | 6.0000 | st 10700787 | Taptite M3x6 bolkoppozidr/zwrt | 30.0000 | st
10350732 | Weerstand 1k8 5% 1/4W | 17.0000 | st 10700790 | Taptite M3x6 verzkop/pozidr/zw | 8.0000 | st
10350703 | Weerstand 2E2 5% 1/4W | 24.0000 | st 10951003 | VU meter AL19-WF / 24v lamp | 3.0000 | st
10350733 | Weerstand 2k2 5% 1/4W | 11.0000 | st 10951001 | VU meter AL29-WF / 24v lamp | 3.0000 | st
10350842 | Weerstand 3k01 1% 1/4W | 1.0000 | st
10350735 | Weerstand 3k3 5% 1/4W | 2.0000 | st 60883310 Cinemix dual inline channel
10350736 | Weerstand 3k9 5% 1/4W | 12.0000 | st -------------------------------------------------------------------------------------------------
10350737 | Weerstand 4k7 5% 1/4W | 16.0000 | st Articlecode | Description | Quantity | Unit
10350738 | Weerstand 5k6 5% 1/4W | 2.0000 | st -------------------------------------------------------------------------------------------------
10350739 | Weerstand 6k8 5% 1/4W | 17.0000 | st 10400213 | Condensator ker 10p R2.5 | 12.0000 | st
10350740 | Weerstand 8k2 5% 1/4W | 3.0000 | st 10400215 | Condensator ker 15p R2.5 | 2.0000 | st
10350705 | Weerstand 10E 5% 1/4W | 10.0000 | st 10400216 | Condensator ker 18p R2.5 | 11.0000 | st
10350776 | Weerstand 10M0 5% 1/4W | 6.0000 | st 10400217 | Condensator ker 22p R2.5 | 1.0000 | st
10350741 | Weerstand 10k 5% 1/4W | 153.0000 | st 10400221 | Condensator ker 47p R2.5 | 3.0000 | st
10350848 | Weerstand 10k0 1% 1/4W | 169.0000 | st 10400232 | Condensator ker 470p R2.5 | 1.0000 | st
10350742 | Weerstand 12k 5% 1/4W | 3.0000 | st 10401241 | Condensator ker 100nF/50V R5 T | 69.0000 | st
10350743 | Weerstand 15k 5% 1/4W | 3.0000 | st 10401246 | Condensator poly 1n0 R5.0 | 2.0000 | st
10350852 | Weerstand 15k0 1% 1/4W | 1.0000 | st 10401247 | Condensator poly 1n5 R5.0 | 2.0000 | st
10350853 | Weerstand 15k8 1% 1/4W | 59.0000 | st 10401268 | Condensator poly 1uF R5.0 | 3.0000 | st
10350744 | Weerstand 18k 5% 1/4W | 5.0000 | st 10401250 | Condensator poly 4n7 R5.0 | 2.0000 | st
10350856 | Weerstand 20k0 1% 1/4W | 20.0000 | st 10401251 | Condensator poly 6n8 R5.0 | 4.0000 | st
10350709 | Weerstand 22E 5% 1/4W | 1.0000 | st 10400277 | Condensator poly 22n R5.0 | 2.0000 | st
10350745 | Weerstand 22k 5% 1/4W | 1.0000 | st 10401258 | Condensator poly 47n R5.0 | 6.0000 | st
10350859 | Weerstand 24k3 1% 1/4W | 4.0000 | st 10401260 | Condensator poly 68n R5.0 | 2.0000 | st
10350746 | Weerstand 27k 5% 1/4W | 3.0000 | st 10401242 | Condensator poly 82n R5.0 | 2.0000 | st
10350713 | Weerstand 47E 5% 1/4W | 64.0000 | st 10401261 | Condensator poly 100n R5.0 | 2.0000 | st
10350749 | Weerstand 47k 5% 1/4W | 30.0000 | st 10400270 | Condensator poly 470n R5.0 | 2.0000 | st
10350714 | Weerstand 56E 5% 1/4W | 1.0000 | st 10250342 | Diode 1N4148(signaal) | 2.0000 | st
10350717 | Weerstand 100E 5% 1/4W | 2.0000 | st 10400279 | Elco 1uF / 63V radiaal R5.0 | 2.0000 | st
10350753 | Weerstand 100K 5% 1/4W | 99.0000 | st 10400292 | Elco 100uF / 25V radiaal R5.0 | 35.0000 | st
10350719 | Weerstand 150E 5% 1/4W | 4.0000 | st 10400302 | Elco 100uF / 63V radiaal R5.0 | 3.0000 | st
10350755 | Weerstand 150K 5% 1/4W | 2.0000 | st 10400280 | Elco 2.2uF / 50V radiaal R5.0 | 2.0000 | st
10350720 | Weerstand 180E 5% 1/4W | 1.0000 | st 10400290 | Elco 220uF / 25V radiaal R5.0 | 5.0000 | st
10350756 | Weerstand 180K 5% 1/4W | 3.0000 | st 10400303 | Elco 1000uF / 10V radiaal R5.0 | 1.0000 | st
10350721 | Weerstand 220E 5% 1/4W | 8.0000 | st 10250338 | Fet J112 (N-channel switch) | 3.0000 | st
10350757 | Weerstand 220K 5% 1/4W | 3.0000 | st 10250017 | Fet J175 (P-channel switch) | 3.0000 | st
10350725 | Weerstand 470E 5% 1/4W | 9.0000 | st 10600511 | Header 3p Lock straightR 2.54) | 3.0000 | st
10350761 | Weerstand 470k 5% 1/4W | 20.0000 | st 10600512 | Header 4P lock straight(R2.54) | 4.0000 | st
10350726 | Weerstand 560E 5% 1/4W | 70.0000 | st 10600456 | Header haaks 20p (raster 2.54) | 1.0000 | st
10350763 | Weerstand 680k 5% 1/4W | 12.0000 | st 10600140 | Header haaks 34p (raster 2.54) | 3.0000 | st
10250340 | Zenerdiode 2V4 / 400mW | 7.0000 | st 10600141 | Header haaks 64p (raster 2.54) | 2.0000 | st
10250351 | Zenerdiode 5V6 / 400mW | 4.0000 | st 10600478 | Header recht 4p (raster 2.54) | 6.0000 | st
10250353 | Zenerdiode 12V0 / 1W | 5.0000 | st 10600435 | Header recht 10p nobox(R 2.54) | 5.0000 | st
10250359 | Zenerdiode 15V0 / 400mW | 1.0000 | st 10250004 | Ic 4053B (HCF4053 BEY)switch | 16.0000 | st
10250350 | Zenerdiode 18V0 / 400mW | 3.0000 | st 10250005 | Ic 4093B (snand) | 1.0000 | st
10700652 | Afstandshdr pl zeskant+tap15mm | 1.0000 | st 10250094 | Ic 4094 (8bit serial shiftreg) | 4.0000 | st
10650446 | Bandkabel 10p (R 1.27) | 10.0000 | cm 10250291 | Ic 7805 TO220 SGS (volt.reg) | 1.0000 | st
10650448 | Bandkabel 20p (R 1.27) | 60.0000 | cm 10250307 | Ic NE-5532 AP TI (dual-opamp) | 4.0000 | st
10650159 | Bandkabel 34p (R 1.27) | 160.0000 | cm 10250306 | Ic NE-5534 AP TI(single-opamp) | 1.0000 | st
10700630 | Bout M 2 x 4 verzonken zwart | 8.0000 | st 10250184 | Ic SSM-2017 P (audio pre-amp) | 1.0000 | st
10600173 | Conn: 3p wrd:402-03*20cm 2.5T | 2.0000 | st 10250032 | Ic THAT 2180-LB VCA | 2.0000 | st
10600169 | Conn: 4p wired:1=blk/grn/rd/bl | 2.0000 | st 10250304 | Ic TL-072 CP TI (dual-opamp) | 7.0000 | st
10600434 | Connector bandkabel female 10p | 2.0000 | st 10250305 | Ic TL-074 CN TI (quad-opamp) | 2.0000 | st
10600466 | Connector bandkabel female 16p | 6.0000 | st 10600394 | Ic-voet 8 pins (vork-contact) | 13.0000 | st
10600132 | Connector bandkabel female 34p | 8.0000 | st
10600136 | Connector bandkabel male 20p | 8.0000 | st
10450153 | Deksel SiFam 11mm black/5bulk | 5.0000 | st
10450195 | Deksel SiFam 11mm gray bulk | 10.0000 | st
10450016 | Deksel Sifam 21mm red bulk | 1.0000 | st
10450017 | Deksel Sifam 38mm gray bulk | 1.0000 | st
