Cinemix's SET menu
When you press Cinemix's Setup (S4) switch, the LC Display
reads as follows:
By pressing Mod (S1) the following display will be shown.
In this menu you can assign the module to be Mono/Stereo and you can give it a
number, preferable corresponding with the module number of course.
These selections are made with S2 S3 and S4
By pressing the Dyn switch (S2) depending upon you have that option you see “
No dynamics option” or the Cinemix will enter the dynamics Setup menus.
In this menu you can give a specific VCA a name such as Mstr Rght for instance.
By pressing the Macro switch (S4) the following menu will be
shown.
Now you can select one of the M1 to M4 macro keys located nearby the master
fader. The LCD will change into the following display. See example>
The next step is to select one or more of the input modules by pushing the ARM
switches. Now the selected macro key will activate all selections made now in
the ARM area, such as Tape, routing, Fdr cal etc etc. As soon
as you leave the menu by hitting the esc switch the macro key
will hold the programmed information.
The other possibility in the macro Setup menu is the fader
calibration with S4 for the upper (channels) part of the Cinemix input modules.
Every module that is selected in the fader cal mode will be set at unity gain ideal
for STEMS (pre-mix) returns. It is a setup for a dir/playback macro for tape.
DimL
When the Dim level (S4) is selectedthe following menu will be
shown >
The dim level will be substracted from the preset level and
adjustment is made via the Data entry knob
Note:
In the Setup menu (top layer) The < switch shows you the console setup, its
internal Eprom version and the software date.
The > switch activates and deactivates all mutes in the console .
Cinemix manual page: 27
CRM: -10dB
