Operating Instructions BD Controller 101N07xx Series 24 V DC
14
DEHC.PS.100.I.02
Customer
register
Register 1 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 2 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 3 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 4 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 5 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 6 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 7 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 8 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 9 Custom-designed interface parameter 65535 65535 0 1 Setting
Register 10 Custom-designed interface parameter 65535 65535 0 1 Setting
Actual error
Actual error
0=Noerror
1=Voltagefailure
2=Fanfailure
3=Motorfailure
4=Min.speedfailure
5=Max.speedfailure
6=Thermalfailure
7=NTCSensorFailure
Measurement
Inverter
temperature
(PCB)
Inverter temperature
(PCB)
Controller overheating protection ºC Measurement
Compressor restart delay
Delay before restart after overheating
of inverter
60 120 60 1 Seconds Setting
Parameter Parameter Group Description Default Max value Min value Step Unit Type
Thermostat Thermostat type
Detect mechanical or NTC sensor
thermostat
Auto Electronic Setting
Cutout temperature
Compressor cuts out below cutout
temperature
+25 +40 -40 1
Celsius
(ºC)
Setting
Difference 3 15 1 1 Kelvin (K) Setting
Forced ON
Force thermostat operation to con-
tinuously ON or OFF
OFF ON OFF 1 Setting
Runtime
During cooling OFF (Thermostat cut-
out),theRuntimewillshowthetime
for the last cooling period. Runtime is
reset at cooling ON period. At power-
up the reading is reset.
1 Minutes Measurement
Actual temperature
Real-time air temperature when an
NTC sensor is used. When a mechani-
calthermostatisused,onlythermo-
stat status ON or OFF is displayed.
ºC Measurement
Compressor
safety
Compressor restart time
Delay before restart after short
cycling
60 120 60 1 Seconds Setting
Communication Node Number Modbus address 1 247 1 1 Setting
Bits per seconds Communication speed 19200 19200 9600 9600 bps Setting
Communication options
0=Disabled
1=Enabled
0 1 0 1 Setting
Communication timeout
Maximum duration of each communi-
cation attempt
900 7200 15 1 seconds Setting
Setting protection code
&status
Privacy function code must be
entered twice
0 9999 0 1 Setting
Product
information
Unit name
The user’s own identification name
for the unit can be entered here
(optional)
Setting
Vendor name Vendor name Measurement
Product code no Danfoss product code number Measurement
Software version Controller software version Measurement
Unit ID Danfoss unit ID Measurement
Production date Danfoss production date Measurement
Lot no Danfoss lot no. Measurement
Serial no Danfoss serial no. Measurement
