Danfoss 101N0715 User Manual

TOOL
COOL
4
®
BD Controller
101N07xx Series
24 V DC
5
DEHC.PS.100.I1.02
1.1 Applications
1. Introduction
The BD350GH 24 V DC compressor system is intended mainly for in parking anti-idle applications.
Secondary applications could be
• Spotcoolinginbuses,golfcarts,smallerboats,forklifts,campersetc
• Aircargocooling
• Coolingofswitchboardsandbatteriesinradiostationsforcellularphones
1.2 Capability
The cooling capacity of the compressor is approx. 900 Watt @ Pe/Pc ~+15/+55°C
The system is able to operate in ambient temperatures up to +55 ºC (131 F).
The operating conditions are High Back Pressure (HBP).
1.3 Functions
The main functions of BD350GH compressor systems are:
• Motor/Compressorspeedcontrol
• Thermostatcontrol(ON/OFForelectronicviaNTCtemperaturesensor)
• ECOfunctiontooptimizecompressorspeedforminimumpowerconsumption
• Condenserfancontrol
• Evaporatorfancontrol
• Communicationinterface
• Monitoringfunction
• Error&eventlog
• Batteryprotectionfunctions
• MainSwitch
• Logofspecicparameters
• OptimizationofspecicparametersviaPCsoftwarebeforecommencingmassproduction
1.4 Programming
Interface
The controller can be accessed using either
-theDanfosssoftwaretool,Tool4Cool®LabEdition,or
- a custom interface. Please contact Danfoss for further information regarding custom interfaces.
