Operating Instructions BD Controller 101N07xx Series 24 V DC
17
DEHC.PS.100.I1.02
4.2.4 Condenser fan
Thespeedofthecondenserfancanbecontrolledinordertosaveenergy,reducenoiseandoptimize
the fan operation.
Thefanissynchronizedwiththecompressoroperation.
Start and stop delays can be set up as a function of the state of the parameter Thermostat.
Furthermore,thefancanbesettoruncontinuously(forcedONoperation).
Somefandefectsaredetectable,andaredisplayedintheparameterError.
The speed of the fan can be controlled in the range from 40% to 100%.
Measurements
Name Default Max value Min value Step Unit
Cond. Fan voltage 24 31 12 1 Volt
Fan speed 100 100 40 10 %
Fan start delay 0 240 0 1 Seconds
Fan stop delay 0 240 0 1 Seconds
Fan forced ON OFF ON OFF 1 -
Detect missing fan OFF ON OFF 1 -
Name Description Step Unit
Fan speed Actual fan speed 1 %
4.2.5 Evaporator fan
Thespeedoftheevaporatorfancanbecontrolledinordertosaveenergy,reducenoiseandoptimize
the fan operation.
Thefanissynchronizedwiththecompressoroperation.
Start and stop delays can be set up as a function of the state of the parameter Thermostat.
Furthermore,thefancanbesettoruncontinuously(forcedONoperation).
Somefandefectsaredetectable,andaredisplayedintheparameterError.
The speed of the fan can be controlled in the range from 40% to 100%.
Settings
Measurements
Name Default Max value Min value Step Unit
Evap. Fan voltage 24 31 12 1 Volt
Fan speed 100 100 40 10 %
Fan start delay 0 240 0 1 Seconds
Fan stop delay 0 240 0 1 Seconds
Fan forced ON OFF ON OFF 1 -
Detect missing fan OFF ON OFF 1 -
Name Description Step Unit
Fan speed Real-time fan speed 1 %
Settings
