BD Controller
101N07xx Series
24 V DC
13
DEHC.PS.100.I1.02
4. Parameters
Parameter Group Parameter Description Default Max value Min value Step Unit Type
Main functions Main switch
On/Off regulation of power supply to
controller
OFF ON OFF 1
Battery
protection
Battery cutout level
Battery protection cut-out voltage
level
21.3 27 19 0.1 Volt Setting
Battery cutin diff.
Voltage difference between battery
cut-in and cut-out
3.9 10 0.5 0.1 Volt Setting
Cutout delay
Time to cut-out when non-critical
battery protection implemented
3 60 0 1 Seconds Setting
Cut-in level
Calculated value.
Cutin=Cutout+Di.
0.1 Volt Measurement
Supply voltage
Real-time voltage measured
on+&-terminals
0.1 Volt Measurement
Compressor Requested speed
Compressor speed and therefore
capacity definition
4000 4000 2500 100 rpm Setting
Start delay
Time to start after
compressor is switched ON
4 240 2 1 Seconds Setting
Start speed
Optional startup speed lower than
Requestedspeed,duringtheperiod
Start time.
2500 4000 2500 100 rpm Setting
Start time
Period of time elapsing after startup
of compressor until Requested speed
is reached
30 600 0 1 Seconds Setting
Compressor speed Real-time speed (+/- 10%) 1 rpm Measurement
Condenser fan Cond. Fan voltage
Supply voltage to the
condenser fan.
24 31 12 1 Volt Setting
Fan speed
Condenserfanspeedsynchronized
with compressor operation
100 100 40 10 % Setting
Fan start delay
Time to start as a function of
Thermostat
0 240 0 1 Seconds Setting
Fan stop delay
Time to stop as a function of
Thermostat
0 240 0 1 Seconds Setting
Fan forced ON
Force condenser fan continuously
ON or OFF
OFF ON OFF 1 Setting
Detect missing fan
Detect whether condenser fan is
connected
OFF ON OFF 1 Setting
Fan speed Real-time condenser fan speed 1 % Measurement
Evaporator fan Evap. Fan voltage Supply voltage to the evaporator fan. 24 31 12 1 Volt Setting
Fan speed
Evaporator fan speed
synchronizedwith
compressor operation.
100 100 40 10 % Setting
Fan start delay
Time to fan start as a
function of Thermostat
0 240 0 1 Seconds Setting
Fan stop delay
Time to fan stop as a
function of Thermostat
0 240 0 1 Seconds Setting
Fan forced ON
Force evaporator fan
continuously ON or OFF
OFF ON OFF 1 Setting
Detect missing fan
Detect whether evaporator fan is
connected
OFF ON OFF 1 Setting
Fan speed Real-time evaporator fan speed 1 % Measurement
The user can change settings and observe real-time measurements (read-only)
in the following parameters.
The table in 4.1 Parameter Overview is intended for easy reference.
For more detail, please refer to 4.2 Description of Parameter Groups.
4.1 Parameter
Overview
