2.3 Install and
configure
software
Wire dimensions
The compressor control unit has the following connections:
I,C,+ Modbusdatacommunication.I=communicationC&+powersupply.
C,T Thermostatconnection.ADanfossNTCtemperaturesensor(option2)canbeconnectedora
mechanical ON/OFF thermostat (option 1)
Fe,+ Evaporatorfan(Optional)24VDC,0-24V,max60Wattpoweroutput,pulsewidth 
modulated.
Fc,+ Condenserfan(optional)24VDC,0-24V,max40Wattpoweroutput,pulsewidth
modulated.
-,+ Mainsupplyvoltage.Nominalvoltage24VDC,range:17to31.5VDC
Size Max. length*
24V operation
Cross
section
[mm
2
]
AWG
[Gauge] [m] [ft.]
2 x 4
2 x 6
11
9
1.5
2
4.92
6.60
For brief software installation and configuration instructions please refer to BD Controller 101N07xx
Series 24 V DC with Tool4Cool® LabEdition Software - Quick Start Guide.
For detailed instructions please refer to Tool4Cool® LabEdition Operating Instructions.
ThesemanualsaresuppliedwiththeTool4Cool®software.
* Length between battery and electronic unit
