Operating Instructions BD Controller 101N07xx Series 24 V DC
18
DEHC.PS.100.I.02
4.2.6 Thermostat
Thermostat type
Twotypesofthermostatcanbeutilizedfortemperaturecontrol.
Electronic thermostat (NTC sensor)
Disconnected sensor error alarm (NTC sensor failure) is sent when the measured temperature is > +100ºC
Short circuited sensor error alarm (NTC sensor failure) is sent when the measured temperature < - 60ºC
Mechanical thermostat
AmechanicalON/OFFthermostatcanbeconnectedatterminalsC&T.
No detection of faulty thermostat is provided when an ON/OFF thermostat is used.
Automatic thermostat selection
The Thermostat parameter displays the type of thermostat connected to the controller: either a me-
chanical thermostat or NTC temperature sensor.
An NTC sensor is recommended for the temperature range -60 ºC to +100 ºC
A mechanical thermostat is recommended for temperatures below -60 ºC and above +100 ºC
Note: An NTC sensor error is not detectable when the NTC sensor is operating in automatic thermo-
stat selection mode.
Settings
Name Default Max value Min value Step Unit
Thermostat type Auto Electronic - - -
Cutout temperature + 25 + 40 -40 1 Celcius (ºC)
Difference 3 15 1 1 Kelvin (K)
Forced ON OFF ON OFF 1 -
Name Description Step Unit
Runtime Runtime is provided to record cooling-time
(thermostat cut-in period). The runtime is
updatedduringcooling,startingwith0at
start of cooling.
DuringcoolingOFF(Thermostatcut-out),
the Runtime parameter will show the time for
the last cooling period. Runtime is reset at
thebeginningofacoolingONperiod,andat
power-up.
1 Minutes
Actual temperature Real-time air temperature when a NTC sensor
is used.
Whenamechanicalthermostatisused,only
thermostat status ON or OFF is displayed.
- ºC
