VLT
®
MICRO
Receiving, Transporting, Inspecting, and Storage
This VLT
®
MICRO Adjustable Frequency Drive has gone through rigorous quality control
tests at the factory before shipment. After receiving and before transporting the drive,
check for the following.
Receipt
After receiving the AC drive, inspect the unit to insure it was not damaged during
shipment.
Transportation
Climatic condition : Class 2K3
Inspection
• After unpacking the unit, make sure that the package includes a drive unit and the
Instruction Manual.
• Make sure that the part number indicated on the nameplate and packing carton
corresponds with the part number of your order.
Storage
The AFD should be kept in the shipping carton before installation. In order to retain the
warranty coverage, the drive should be stored properly. Some storage
recommendations are:
• Store in a clean, dry place
• Store within an ambient temperature range of -20°C to +65°C
• If possible, store in an air-conditioned evironment where the relative humidity is less
than 95%, non-condensing.
• Do not store the unit in places where it could be exposed to corrosive gases.
• Do not store the unit on an unstable surface where it could be damaged by falling to
the floor.
Nameplate Information
Example for 1HP 240V AC Adjustable Frequency Drives
Description of Serial Number
1234 01 H 260
Production date:
week, year
Place of production
Series number
Serial number
Part Numbers:
1/2HP 230V single phase 176F7300
1HP 230V single phase 176F7301
2HP 230V single phase 176F7302
1/2HP 230V three phase 176F7303
1HP 230V three phase 176F7304
2HP 230V three phase 176F7305
1/2HP 230V single phase CE 176F7306
1HP 230V single phase CE 176F7307
2HP 230V single phase CE 176F7308
2
