VLT
®
MICRO
No. Parameter Function Parameter Factory
Name Explanation Value Setting
13 Deceleration time 2 d0.1 - d600. sec d10.0
14 S-curve S-curve d00 - d07 d00
15 Jog Operation Jog acel/decel time d0.1 - d600. sec d1.0
16 Setting Jog frequency d0.1 - d400. Hz d6.00
17 Multi-step Multi-step speed 1 d0.0 - d400. Hz d0.00
18 Operation Multi-step speed 2 d0.0 - d400. Hz d0.00
19 Speeds Multi-step speed 3 d0.0 - d400. Hz d0.00
20 Multi-step speed 4 d0.0 - d400. Hz d0.00
21 Multi-step speed 5 d0.0 - d400. Hz d0.00
22 Multi-step speed 6 d0.0 - d400. Hz d0.0
23 Multi-step speed 7 d0.0 - d400. Hz d0.0
24 REV run REV run inhibit d00:REV run enable d00
inhibit d01:Rev run disable
25 Over-volt Stall Over-voltage stall d00:Disable over-volt stall prevent d01
Prevention prevention d01:Enable over-volt stall prevent
26 Over-current Over-current stall d50 - d200% d170
Stall prevention (during
Prevention acceleration)
27 Over-current stall d50 - d200% d170
prevention (during
operation)
28 DC Braking DC braking current d0.0 - d100% d0.0
29 DC braking time d0.0 - d5.0 sec d0.0
during start-up
30 DC braking time d0.0 - d25.0 sec d0.0
during stopping
31 DC braking start-up d0.0 - d60.0 Hz d0.0
frequency
32 Momentary Momentary power d00:Operation stops after d00
Power Loss loss operation momentary power loss
Protection mode selection d01:Operation continues after
momentary power loss.
Speed search starts with the
frequency reference value.
d02:Operation continues after
momentary power loss.
Speed search starts with the
minimum frequency
63
