Danfoss ECL 2000 Installation Guide

Configuring the ECL 2000
EI.65.D4.02
31
The table below specifies ranges and default values of the parameters Scaling and
Interval.
Sensor Scaling
range
Scaling
default
Unit Interval
range
Interval
default
Sun intens.
0.100 – 0.999
1.00 – 9.99
10.0 – 99.9
100 – 999
10 J/m
2
(per pulse)
2
5 – 3600 60
Wind veloc.
0.100 – 0.999
1.00 – 9.99
10.0 – 99.9
100 – 999
1m
(per
pulse)
3
5 – 3600 60
Water flow
0.0010– 0.0099
0.0100– 0.0999
0.100 – 0.999
1.00 – 9.99
10.0 – 99.9
l
(per pulse)
5 – 3600 60
0.0010– 0.0099
0.0100– 0.0999
0.100 – 0.999
0.001 m³
(per pulse)
Energy
0.0010– 0.0099
0.0100– 0.0999
0.100 – 0.999
1.00 – 9.99
10.0 – 99.9
1kWh
(per pulse)
5 – 3600 60
0.0010– 0.0099
0.0100– 0.0999
0.100 – 0.999
MWh
(per pulse)
Other
1 1 – 5 – 3600 60
Note:
The maximum pulse frequency that can be measured by the ECL 2000 depends on
the number of pulse sensors currently in use with the controller. The maximum
pulse frequency is:
F
max
= 200 Hz/number of pulse sensors in use.
Example 1 A wind speed meter yields 10 Hz pulses at a wind speed of 20 m/s. Scaling and
Interval are set as follows:
• Scaling = 2.0 m (corresponding to 2.0 m/s per Hz)
• Interval = 60 s.
2
J/m
2
(per pulse) is equivalent to W/m
2
(per Hz)
3
m (per pulse) is equivalent to m/s (per Hz)
