Danfoss EET Series User Manual

Parameters
EETc 11, 12, 21 and 22
Assignment
Table 4: Assignment
Parameter name
Code
Default
value
Min.
Max.
Description
Assignment
ASi
Sensor Type
NTC10K
NTC5K
NTC10K
Sensor type (all sensors must be of same type)
NTC5K - NTC 5000 Ohm at 25 °C (Beta value=3980 @ 25/100 °C)
NTC10K - NTC 10000 Ohm at 25 °C (Beta Value 3980 @ 25/100 °C)
S2 Conguration
S2C
EuA
nC
dES
Desired conguration for S2 port
nC - Not used/congured
Con - Condenser Sensor
EuA - Defrost/evaporator Sensor
doC - Door Sensor (Normally closed type)
doo - Door Sensor (Normally open type)
ESP - Eco Switch - Push button type
ESt - ECO Switch - Toggle type
dES - Defrost switch - Push Button type only
Relay 2 Conguration
(applicable only for EETc 2x series)
o2C
dEF
nC
Fan
Desired conguration for relay 2
nC - Not Connected
dEF - Congured for defrost heater or defrost valve
Fan - Congured for evaporator fan
Thermostat
Table 5: Thermostat
Parameter name
Code
Default
value
Min.
Max.
Description
Thermostat
THE
Lowest Temperature Limit (°C)
LSE
0
-100
120
Cut-out temperature at coldest position of the spindle (thermostat knob)
Highest Temperature Limit (°C)
HSE
10
-100
120
Cut-out temperature at warmest position of the spindle (thermostat knob)
Lowest Temperature
Dierential (K)
Ldi
2
1
50
The
dierence between the cut-out and the cut-in at coldest position of the ther-
mostat.
Highest Temperature
Dierential (K)
Hdi
2
1
50
The
dierence between the cut-out and the cut-in at warmest position of the ther-
mostat.
Initial pull down ON/OFF
IPE
OFF
OFF
ON
Initial Pull down
OFF - Disable
ON - Enable
Initial Pull Down (IPD) provides faster cooling when the cabinet is powered up with
warmer inside temperature. During IPD, defrost will be skipped until the cabinet air
temperature reaches the cut-out temperature or the IPD duration expires. IPD oper-
ates only during power-up and can be enabled/disabled using this parameter.
Initial Pull down duration (Hrs)
IPD
0
0
120
Maximum time initial pull down can run. Initial pull down will terminate as soon as
this time expires regardless of the cabinet air temperature
Initial pull down initiate tempera-
ture (°C)
Pit
50
-50
120
It indicates the temperature at which initial pull down will be initiated.
• At Power-up: If the cabinet air temp. > Pit for more than 5 minutes, this will trig-
ger the Initial pull down.
Compressor
Table 6: Compressor
Parameter name
Code
Default
value
Min.
Max.
Description
Compressor
COP
Min Run time (Sec.)
Crt
0
0
1800
To prevent the compressor from frequent cut-outs, it ensures that the compressor
runs for at least the specied time. It overrides the cut-out temperature. (Tip: Setting
it too high could lead to unneccessary deep temperatures)
Min Stop time (Sec.)
CSt
120
0
1800
To prevent the compressor from frequent cut-ins, the parameter ensures that the
compressor remains o for at least the specied time under this parameter. It over-
rides the cut-in temperatures. (Tip: Setting it too high could lead to unneccessary
warm temperatures)
© Danfoss | Climate Solutions | 2023.07 BC320944106159en-000301 | 17
Refrigeration controller, type EET series
