System protection
Table 11: System protection
Parameter name
Code
Default
value
Min.
Max.
Description
System Protection
SyP
Voltage Protection function
uPt
No
No
Yes
This feature protects the compressor if the line voltage goes beyond the operating
range.
Minimum Cut-in Voltage 110 V (230
V)
uLi
100
70
230
The lowest voltage at which the compressor is allowed to cut in.
Minimum Cut out Voltage 110 V
(230 V)
uL0
95
70
225
If the voltage goes below this value when the compressor is running, the compres-
sor will be switched o. It is meant to avoid sudden switching on and o of com-
pressor due to voltage uctuations. This cut-o voltage will override compressor
minimum run time.
Maximum cut out Voltage 110V
(230V)
uHi
260
110
270
When the compressor is running, it will be switched OFF if the voltage exceeds this
value. If the compressor is already stopped, it will remain switched o.
Condenser Alarm Limit (°C)
CAL
80
0
120
It sets the condenser temperature at which an alarm will be generated
Condenser Block Limit (°C)
CbL
85
0
120
It sets the compressor switched o due to high condenser temperature.
Condenser OK Limit (°C)
CoL
60
0
120
It sets the compressor to switch on again after it has been switched o due to high
condenser temperature, respecting minimum compressor stop time.
Control sensor error handling type
EHd
Aut
no
Aut
Method to control the cooling cycle in case of cabinet air sensor error:
“no” : no sensor error handling
“SEt” : follow congured error run and stop time.
“Aut” : control automatically based on past cycles time.
Error Run Time (Mins)
Ert
0
0
60
Cooling cycle ON time in case of cabinet sensor error (active only if EHd=Set)
Error Stop Time (Mins)
Est
0
0
60
Cooling cycle OFF time in case of cabinet sensor error (active only if EHd=Set)
Zero Cross Cong
ZC
Yes
No
Yes
It enhances the relay life and avoids relay sparks during relay ON and OFF. If “Yes” is
selected, the relays will be switched ON and OFF when the line-voltage is closeer to
zero.
Test Mode
Table 12: Test Mode
Parameter name
Code
Default
value
Min.
Max.
Description
Test Mode
tst
Operating mode
tSt
Normal
Manual
Normal
Normal mode - Normal operation mode of the controller
Manual mode- In this mode, output relays can be switched ON and OFF irrespective
of temperature conditions.
Service
Table 13: Service
Parameter name
Code
Default
value
Min.
Max.
Description
Service
Ser
Parameter Version
Par
0
0
65535
OEM/Customer can use it to assign Parameter version
Software Version
Fir
0
65535
Software /Firmware version of the controller
Code number
onL
0
65535
Last four digits of the FG code number of the controller
OEM low
oEL
0
65535
OEM/customer can use it to assign their code number for their various applications
OEM High
oEH
0
65535
OEM/customer can use it to assign their code number for their various applications
Thermostat cut in temperature (°C)
CTi
-100
200
Thermostat cut-in temperature at current spindle position
Themostat cut out temperature (°C)
CTO
-100
200
Thermostat cut-out temperature at current spindle position
Cabinet Air Temperature (°C)
Cab
-100
200
Cabinet Air temperature
Evaporator Temperature (°C)
Eva
-100
200
Evaporator Temp
Condenser Temperature (°C)
Con
-100
200
Condenser Temp
Door Status
Dor
Open
Not con-
gured
Status of the door switch
Close: door is closed
Open: door is open
Not Congured: door switch is not congured
Di Switch Status
Di1
Open
Not con-
gured
Status of Digital input:
Open: deactivated
Close: activated
Not Congured: Di switch not congured
Spindle position (%)
uSp
0
100
Current position of the spindle
Warm - 0%
Cold -100%
Refrigeration controller, type EET series
© Danfoss | Climate Solutions | 2023.07 BC320944106159en-000301 | 20
