Danfoss EvoFlat 4.0 M User Manual

Installation Guide EvoFlat 4.0 Flat Stations for apartments, single- and multi-family houses
© Danfoss | DCS-SGDPT | 2022.01
AN40274706699301-010101 | 9
EN
2
4 38
33
5
59 24
40
17
2 Plate heat exchanger DHW
4 Differential pressure controller
5 Stainer
7 Ball valve
9 DHW circulation set with safety valve
12 Safety valve
17 Air vent
23 Sensor pocket
24 Fitting piece for energy meter 3/4” × 110 mm
38 Hot Water Controller
40 Summer By-pass
59 Fitting piece for water meter 3/4” × 110 mm
Connections:
1. Domestic cold water (DCW) inlet
2. Domestic hot water (DHW)
3. Domestic cold water (DCW) outlet
4. Heating (HE) supply
5. Heating (HE) return
4.3 EvoFlat 4.0 W. Construction and Diagrams.
530
65 65 65 65 17496
613
64
8
36 69
1 2 3 4 5
2
17
33
33
4
38
33
33
5
40
59
9127
23
23
24
DHW
DCW
DCW
DHW-C
DH
Supply
DH
Return

Danfoss EvoFlat 4.0 M Specifications

General

Brand	Danfoss
Model	EvoFlat 4.0 M
Category	Industrial Equipment
Language	English
