Mains supply 3 x 525 - 600 VACNormal overload 110% for 1 minute - continued
Size: P1K1 P1K5 P2K2 P3K0
P3K
7
P4K0 P5K5 P7K5 P11K P15K P18K P22K P30K P37K P45K P55K P75K P90K
Max. input current
Continuous
(3 x 525-600 V ) [A]
2.4 2.7 4.1 5.2 - 5.8 8.6 10.4 17.2 20.9 25.4 32.7 39 49 59 78.9 95.3 124.3
Intermittent
(3 x 525-600 V ) [A]
2.7 3.0 4.5 5.7 - 6.4 9.5 11.5 19 23 28 36 43 54 65 87 105 137
Max. pre-fuses
1)
[A]
10 10 20 20 - 20 32 32 63 63 63 63 80 100 125 160 250 250
Environment:
Estimated power loss
at rated max. load [W]
4)
50 65 92 122 - 145 195 261 300 400 475 525 700 750 850 1100 1400 1500
Weight enclosure
IP20 [kg]
6.5 6.5 6.5 6.5 - 6.5 6.6 6.6 12 12 12 23.5 23.5 23.5 35 35 50 50
Weight enclosure
IP21/55 [kg]
13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2 23 23 23 27 27 27 45 45 65 65
Efficiency
4)
0.97 0.97 0.97 0.97 - 0.97 0.97 0.97 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
Table 9.6:
5)
With brake and load sharing 95/ 4/0
Specifications
VLT
®
HVAC Drive Operating Instructions
MG.11.AD.02 - VLT
®
is a registered Danfoss trademark 139
