0-20 Display Line 1.1 Small
Option: Function:
[1667] Pulse Input #29
[Hz]
Actual value of the frequency applied at
terminal 29 as a pulse input.
[1668] Pulse Input #33
[Hz]
Actual value of the frequency applied at
terminal 33 as a pulse input.
[1669] Pulse Output
#27 [Hz]
Actual value of pulses applied to
terminal 27 in digital output mode.
[1670] Pulse Output
#29 [Hz]
Actual value of pulses applied to
terminal 29 in digital output mode.
[1671] Relay Output
[bin]
View the setting of all relays.
[1672] Counter A View the present value of Counter A.
[1673] Counter B View the present value of Counter B.
[1675] Analog In
X30/11
Actual value of the signal on input
X30/11 (General Purpose I/O Card.
Option)
[1676] Analog In
X30/12
Actual value of the signal on input
X30/12 (General Purpose I/O Card.
Optional)
[1677] Analog Out
X30/8 [mA]
Actual value at output X30/8 (General
Purpose I/O Card. Optional) Use
par. 6-60 Terminal X30/8 Output to select
the variable to be shown.
[1680] Fieldbus CTW 1 Control word (CTW) received from the
Bus Master.
[1682] Fieldbus REF 1 Main reference value sent with control
word via the serial communications
network e.g. from the BMS, PLC or other
master controller.
[1684] Comm. Option
STW
Extended fieldbus communication
option status word.
[1685] FC Port CTW 1 Control word (CTW) received from the
Bus Master.
[1686] FC Port REF 1 Status word (STW) sent to the Bus
Master.
[1690] Alarm Word One or more alarms in a Hex code (used
for serial communications)
[1691] Alarm Word 2 One or more alarms in a Hex code (used
for serial communications)
[1692] Warning Word One or more warnings in a Hex code
(used for serial communications)
[1693] Warning Word
2
One or more warnings in a Hex code
(used for serial communications)
[1694] Ext. Status
Word
One or more status conditions in a Hex
code (used for serial communications)
[1695] Ext. Status
Word 2
One or more status conditions in a Hex
code (used for serial communications)
0-20 Display Line 1.1 Small
Option: Function:
[1696] Maintenance
Word
The bits reflect the status for the
programmed Preventive Maintenance
Events in parameter group 23-1*
[1830] Analog Input
X42/1
Shows the value of the signal applied to
terminal X42/1 on the Analog I/O card.
[1831] Analog Input
X42/3
Shows the value of the signal applied to
terminal X42/3 on the Analog I/O card.
[1832] Analog Input
X42/5
Shows the value of the signal applied to
terminal X42/5 on the Analog I/O card.
[1833] Analog Out
X42/7 [V]
Shows the value of the signal applied to
terminal X42/7 on the Analog I/O card.
[1834] Analog Out
X42/9 [V]
Shows the value of the signal applied to
terminal X42/9 on the Analog I/O card.
[1835] Analog Out
X42/11 [V]
Shows the value of the signal applied to
terminal X42/11 on the Analog I/O card.
[1836] Analog Input
X48/2 [mA]
[1837] Temp. Input
X48/4
[1838] Temp. Input
X48/7
[1839] Temp. Input
X48/10
[1850] Sensorless
Readout [unit]
[2117] Ext. 1
Reference
[Unit]
The value of the reference for extended
Closed Loop Controller 1
[2118] Ext. 1
Feedback
[Unit]
The value of the feedback signal for
extended Closed Loop Controller 1
[2119] Ext. 1 Output
[%]
The value of the output from extended
Closed Loop Controller 1
[2137] Ext. 2
Reference
[Unit]
The value of the reference for extended
Closed Loop Controller 2
[2138] Ext. 2
Feedback
[Unit]
The value of the feedback signal for
extended Closed Loop Controller 2
[2139] Ext. 2 Output
[%]
The value of the output from extended
Closed Loop Controller 2
[2157] Ext. 3
Reference
[Unit]
The value of the reference for extended
Closed Loop Controller 3
[2158] Ext. 3
Feedback
[Unit]
The value of the feedback signal for
extended Closed Loop Controller 3
[2159] Ext. 3 Output
[%]
The value of the output from extended
Closed Loop Controller 3
