Danfoss FC 300 Profibus User Manual

FC 300 Profibus
How to Control the FC 300
 Status Word according to PROFIdrive Profile
(STW)
The Status word is used to notify a master (e.g. a
PC) about the status of a slave.
Bit Bit = 0 Bit = 1
00 Control not
ready
Control ready
01 Drive not
ready
Drive ready
02 Coasting Enable
03 No error Trip
04 OFF 2 ON 2
05 OFF 3 ON 3
06 Start possible Start not possible
07 No warning Warning
08 Speed ≠
reference
Speed = reference
09 Local
operation
Bus control
10 Out of
frequency
limit
Frequency limit ok
11 No operation In operation
12 Drive OK Stopped,
autostart
13 Voltage OK Voltage exceeded
14 Torque O K Torque exceeded
15 Timer OK Timer exceeded
Explanation of the Status Bits
B
it 00, Control not ready/ready
When bit 00 = "0", bit 00, 01 or 02 of the Control word is "0" (OFF 1, OFF 2 or OFF 3) - or the frequency
converter is switched off (trip).
When bit 00 = "1", the frequency converter control is ready, but there is not necessarily power supply to the
unit present (in the event of external 24 V supply of the control system).
Bit 01, VLT not ready/ready
Same significance as bit 00, however, there is a supply of the power unit. The frequency converter is
ready when it receives the necessary start signals.
Bit 02, Coasting/Enable
When bit 02 = "0", bit 00, 01 or 02 of the Control word is "0" (OFF 1, OFF 2 or OFF 3 or coasting) - or the
frequency converter is switched off (trip).
When bit 02 = "1", bit 00, 01 or 02 of the Control word is "1"; the frequency converter has not tripped.
B
it 03, No error/Trip
When bit 03 = "0", no error condition of the frequency converter exists.
When bit 03 = "1", the frequency converter has tripped and requires a reset signal before it can start.
Bit 04, ON 2/OFF 2
When bit 01 of the Control word is "0", then bit 04 = "0".
When bit 01 of the Control word is "1", then bit 04 = "1".
Bit 05, ON 3/OFF 3
When bit 02 of the Control word is "0", then bit 05 = "0".
When bit 02 of the Control word is "1", then bit 05 = "1".
32
MG.33.C2.02 - VLT is a registered Danfoss trademark
