FC 300 Profibus
How to Control the FC 300
Bit 12, Relay 04
Bit 12 = "0" Relay 04 has not been activated. Bit 12 = "1" Relay 04 has been activated, provided Control
word bit 12 has been chosen in par. 5-40 Function relay.
Bit 13/14, Selection of set-up
Bits 13 and 14 are used to choose from the f our
menu set-ups according to the following table:
The function is only possible when Multi-Set-ups is
selected in par. 0-10 Active Set-up.
Set-up Bit 14 Bit 13
1 0 0
2 0 1
3 1 0
4 1 1
NB!:
In par. 8-55 Set-up select a selection is made to define how Bit 13/14 gates with the corresponding
function on the digital inputs.
B
it 15 Reverse
Bit 15 = "0" causes no reversing.
Bit 15 = "1" causes reversing.
37
MG.33.C2.02 - VLT is a registered Danfoss trademark
