FC 300 Profibus
Troubleshooting
The effect of control mode upon the function of par. 8-53 Start select and 8-54 Reversing select:
If Digital input [0] is selected, the terminals will
control the start and reversin g functions
Digital input [0]
Term i nal Bit 06/15 Function
0 0 Stop/Anti-clockwise
0 1 Stop/Anti-clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise
If Serial communication [1] is selected, commands
will be activated only w hen given via serial
communication.
Serial communication [1]
Term i nal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Start/Clockwise
1 0 Stop/Anti-clockwise
1 1 Start/Clockwise
If Logic AND [2] is selected, both signals must be
activated to perform the function.
Logic AND [2]
Term i nal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Stop/Anti-clockwise
1 0 Stop/Anti-clockwise
1 1 Start/Clockwise
If Logic OR [3] is selected, activation of one signal
will activate the function.
Logic OR [3 ]
Term i nal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Start/Clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise
The effect of control mode upon the function of par. 8-55 Set-up select and 8-56 P reset reference select:
If Digital input [0] is selected, the terminals will
control the set-up and preset reference functions.
Digital input [0]
Term i nal Bit 00/01,
13/14
Function
Msb Lsb Msb Lsb Preset ref., Set-up no.
0 0 0 0 1
0 0 0 1 1
0 0 1 0 1
0 0 1 1 1
0 1 0 0 2
0 1 0 1 2
0 1 1 0 2
0 1 1 1 2
1 0 0 0 3
1 0 0 1 3
1 0 1 0 3
1 0 1 1 3
1 1 0 0 4
1 1 0 1 4
1 1 1 0 4
1 1 1 1 4
79
MG.33.C2.02 - VLT is a registered Danfoss trademark
