8-05 End-of-Timeout Function
Option: Function:
Select the action after receiving a valid control
word following a timeout. This parameter is
active only when 8-04 Control Timeout Function
is set to [Set-up 1-4].
[0] Hold set-up Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
adjustable frequency drive resumes its original
set-up.
[1]
*
Resume set-
up
Resumes the set-up active prior to the timeout.
8-06 Reset Control Word Timeout
This parameter is active only when Hold set-up [0] has been
selected in 8-05 End-of-Timeout Function.
Option: Function:
[0]
*
Do not reset Retains the set-up specified in 8-04 Control
Word Timeout Function, following a control
word timeout.
[1] Do reset Returns the adjustable frequency drive to the
original set-up following a control word
timeout. The adjustable frequency drive
performs the reset and then immediately
reverts to the Do not reset [0] setting
8-07 Diagnosis Trigger
Option: Function:
This parameter enables and controls the
adjustable frequency drive diagnosis function and
permits expansion of the diagnosis data to 24
bytes.
NOTE!
This is only valid for Profibus.
- Disable [0]: Do not send extended
diagnosis data even if they appear in the
adjustable frequency drive.
- Trigger on alarms [1]: Send extended
diagnosis data when one or more alarms
appear in alarm 16-90 Alarm Word or
9-53 Profibus Warning Word.
- Trigger alarms/warn. [2]: Send extended
diagnosis data if one or more alarms or
warnings appear in alarm 16-90 Alarm
Word, 9-53 Profibus Warning Word, or
warning 16-92 Warning Word.
The content of the extended diagnosis frame is as
follows:
8-07 Diagnosis Trigger
Option: Function:
Byte Content Description
0 - 5 Standard DP
Diagnose
Data
Standard DP Diagnose
Data
6 PDU length xx Header of extended
diagnostic data
7 Status type =
0x81
Header of extended
diagnostic data
8 Slot = 0 Header of extended
diagnostic data
9 Status info =
0
Header of extended
diagnostic data
10 - 13 VLT
16-92 Warning
Word
VLT warning word
14 - 17 VLT
16-03 Status
Word
VLT status word
18 - 21 VLT
16-90 Alarm
Word
VLT alarm word
22 - 23 VLT
9-53 Profibus
Warning Word
Communication
warning word (Profibus)
Enabling diagnosis may cause increased bus
traffic. Diagnosis functions are not supported by
all serial communication bus types.
[0]
*
Disable
[1] Trigger
on
alarms
[2] Trigger
alarm/
warn.
Parameter Descriptions FC 300 Programming Guide
3-82 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
