PK 37 PK 55 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical Shaft Output [kW] 0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure IP20 (FC 301 only) A1 A1 A1 A1 A1
Enclosure IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
High overload 160% for 1 min.
Shaft output [kW] 0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Continuous (3x380-440 V) [A] 1.3 1.8 2.4 3 4.1 5.6 7.2 10 13 16
Intermittent (3x380-440 V) [A] 2.1 2.9 3.8 4.8 6.6 9.0 11.5 16 20.8 25.6
Continuous (3x441-500 V) [A] 1.2 1.6 2.1 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent (3x441-500 V) [A] 1.9 2.6 3.4 4.3 5.4 7.7 10.1 13.1 17.6 23.2
Continuous kVA (400 V AC) [kVA] 0.9 1.3 1.7 2.1 2.8 3.9 5.0 6.9 9.0 11.0
Continuous kVA (460 V AC) [kVA] 0.9 1.3 1.7 2.4 2.7 3.8 5.0 6.5 8.8 11.6
Max. input current
Continuous (3x380-440 V) [A] 1.2 1.6 2.2 2.7 3.7 5.0 6.5 9.0 11.7 14.4
Intermittent (3x380-440 V) [A] 1.9 2.6 3.5 4.3 5.9 8.0 10.4 14.4 18.7 23.0
Continuous (3x441-500 V) [A] 1.0 1.4 1.9 2.7 3.1 4.3 5.7 7.4 9.9 13.0
Intermittent (3x441-500 V) [A] 1.6 2.2 3.0 4.3 5.0 6.9 9.1 11.8 15.8 20.8
Additional specifications
IP20, IP21 max. cable cross section
5)
(mains, motor, brake and load
sharing) [mm
2
(AWG)]
2)
4,4,4 (12,12,12)
(min. 0.2(24))
IP55, IP66 max. cable cross section
5)
(mains, motor, brake and load
sharing) [mm
2
(AWG)]
4,4,4 (12,12,12)
Max. cable cross section
5)
with
disconnect
6,4,4 (10,12,12)
Estimated power loss
at rated max. load [W]
4)
35 42 46 58 62 88 116 124 187 255
Weight, enclosure IP20 4.7 4.7 4.8 4.8 4.9 4.9 4.9 4.9 6.6 6.6
Enclosure IP55, IP66 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Efficiency
4)
0.93 0.95 0.96 0.96 0.97 0.97 0.97 0.97 0.97 0.97
0.37-7.5 kW only available as 160% high overload.
Table 10.4 Mains Supply 3x380-500 V AC (FC 302), 3x380-480 V AC (FC 301)
