Danfoss FC 300 User Manual

10.4 Connection Tightening Torques
Power (kW) Torque (Nm)
Enclo-
sure
200-240 V
380-480/500
V
525-600 V 525-690 V Mains Motor
DC
connecti
on
Brake Earth Relay
A2 0.25-2.2 0.37-4.0 1.8 1.8 1.8 1.8 3 0.6
A3 3.0-3.7 5.5-7.5 0.75-7.5 1.1-7.5 1.8 1.8 1.8 1.8 3 0.6
A4 0.25-2.2 0.37-4.0 1.8 1.8 1.8 1.8 3 0.6
A5 0.25-3.7 0.37-7.5 0.75-7.5 1.8 1.8 1.8 1.8 3 0.6
B1 5.5-7.5 11-15 11-15 1.8 1.8 1.5 1.5 3 0.6
B2 11
18
22
18
22
11
22
4.5
4.5
4.5
4.5
3.7
3.7
3.7
3.7
3
3
0.6
0.6
B3 5.5 -7.5 11-15 11-15 1.8 1.8 1.8 1.8 3 0.6
B4 11-15 18-30 18-30 4.5 4.5 4.5 4.5 3 0.6
C1 15-22 30-45 30-45 10 10 10 10 3 0.6
C2 30-37 55 -75 55-75 30-75
14/24
1)
14/24
1)
14 14 3 0.6
C3 18-22 37-45 37-45 45-55 10 10 10 10 3 0.6
C4 30-37 55-75 55-75
14/24
1)
14/24
1)
14 14 3 0.6
Table 10.28 Tightening of Terminals
1)
For different cable dimensions x/y, where x ≤ 95 mm
2
and y ≥ 95 mm
2
.
Specifications
VLT
®
AutomationDrive Operating
Instructions
MG33AM02 - VLT
®
is a registered Danfoss trademark 91
10
10

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
